ECE 343 - Electronic Circuits Laboratory
Design and assembly of power electronics and analog circuitry.
AC-DC Power Supply Design
◦ Design: AC-DC full bridge rectifier + Low Dropout DC-DC converter.
◦ Specs: Converts 120V AC to 10V DC, supplying 100mA.
◦ Skills: Trade-off analysis, Rectifiers, Op-amps, BJT, Zener diodes.
AD-DC Power Supply
Buck Demo
